UNI-T UTE9806+ Power Meter
£320.00
excl. VAT
Unit price
/
Unavailable
£384.00
Incl. VAT
Variants
Variants
This device offers precise AC measurements with a voltage range of 0.5V to 600V and a current range of 0.05mA to 10.0A. It supports frequencies from 40Hz to 400Hz with an accuracy of ± (0.4% reading + 0.1 range + 1 digit). Connectivity options include RS-232/RS-485, and its compact size and VA LCD display ensure convenient operation and readability.
Overview
Overview
| Feature | Specification |
|---|---|
| Model Number | UTE9806+ |
| Voltage Range | 0.5V~600V |
| Current Range | 0.05mA~10.0A |
| Frequency Range | 40Hz~400Hz |
| Accuracy | ± (0.4% reading + 0.1 range + 1 digit) |
| Measurement Mode | AC |
| Connectivity | RS-232/RS-485 |
| Size | ½ 2U |
| Display | VA LCD |
| Voltage Resolution | 0.01V/0.1V |
| Touchscreen | No |
| Warranty | 3 years |
| Shipping Dimensions | 214mm×88mm×340mm |
| Shipping Weight | 3.5 kg |
| For additional product specifications, please refer to the attached PDF. |
|
Related Documents
Related Documents
User Manual
Datasheet
Programming Manual
Software
Couldn't load pickup availability
📹 Related Videos
📹 Related Videos
Apparent power peak measurement
Average function
Data refresh rate adjustable
Upper and lower limit alarm function
Range setting
Range switching
