Specifications
Specifications
-
Bandwidth500MHz
-
Channel4+16
-
Real-Time Sample Rate2.5GSa/s
-
Waveform Capture Rate1.000,000wfms/s
-
Max. Memory Depth250Mpts
-
Waveform Generator50MHz Dual Channels
Description
- Model: UNI-T MSO3504E-S
- Analog Bandwidth: 500 MHz
- Analog Channels: 4
- Digital Channels: 16
- Real-Time Sampling Rate: 2.5 GSa/s (analog), 1.25 GSa/s (digital)
- Input Impedance: 1 MΩ / 50 Ω selectable
- Memory Depth: 70 Mpts per channel; up to 250 Mpts in single or scan mode
- Waveform Capture Rate: Up to 1,000,000 wfms/s
- Waveform Generator: Built-in dual-channel 50 MHz arbitrary/function generator
- AWG Output: Supports real-time output of oscilloscope waveform data to AWG
- Bode Plot: Integrated loop test for system stability analysis
- Waveform Recording: Uninterrupted hardware recording and analysis of up to 120,000 frames
- Math Functions: Add, subtract, multiply, divide, digital filtering, logic, and advanced operations
- FFT Analysis: 1Mpts enhanced FFT with waterfall view, frequency settings, detection, and marker tools
- Parameter Measurements: 36 automatic waveform parameters
- Scan Measurement: Supports parameter measurements while scanning
- Multi-Scopes Mode: Multi-channel independent triggering with phosphor-style Multi-Scopes 2.0 display
- Frequency Counter: Independent 7-digit hardware frequency counters on each channel
- DVM Function: Multi-channel true RMS AC, DC, and AC+DC measurements
- Trigger Types: Edge, Pulse, Video, Slope, Runt, Over Amplitude, Delay, Timeout, Duration, Setup/Hold, Nth Edge, Pattern
- Zone Triggering: Capture rare, accidental, or complex signals accurately
- Protocol Decoding (Optional): RS232, I2C, SPI, CAN, CAN-FD, LIN, FlexRay
- Display: 8-inch capacitive touchscreen (800×480), gesture-supported: click, slide, zoom, edit, drag
- Display Technology: Ultra Phosphor 2.0 with 256 levels of grayscale
- Interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail), AWG, VGA
- Storage & Export: U-disk support for data storage, one-key screenshot, USB software upgrade
- USB Connectivity: Plug-and-play USB device for PC communication
- SCPI Support: Fully SCPI-compatible for automation and remote programming
- Remote Access: Web server for browser-based remote control via PC or mobile
Product comparison
| Facet | ||||
|---|---|---|---|---|
| By | ||||
| By | UNI-T | UNI-T | UNI-T | UNI-T |
| Price | ||||
| Price |
£2,141.00
excl. VAT
Unit price
/
Unavailable
£2,569.20
Incl. VAT
|
£2,399.00
excl. VAT
Unit price
/
Unavailable
£2,878.80
Incl. VAT
|
£707.00
excl. VAT
Unit price
/
Unavailable
£848.40
Incl. VAT
|
£790.00
excl. VAT
Unit price
/
Unavailable
£948.00
Incl. VAT
|
| Bandwidth | ||||
| Bandwidth | 350MHz
| 500MHz
| 100MHz
| 100MHz
|
| Channel | ||||
| Channel | 4+16
| 4+16
| 2 +16
| 4+16
|
| Max. Memory Depth | ||||
| Max. Memory Depth | 250Mpts
| 250Mpts
| 56Mpts
| 56Mpts
|
| Real-Time Sample Rate | ||||
| Real-Time Sample Rate | 2.5GSa/s
| 2.5GSa/s
| 2GSa/s
| 2GSa/s
|
| Waveform Capture Rate | ||||
| Waveform Capture Rate | 1.000,000wfms/s
| 1.000,000wfms/s
| 1.000,000wfms/s
| 1.000,000wfms/s
|
| Waveform Generator | ||||
| Waveform Generator | 50MHz Dual Channels
| 50MHz Dual Channels
| 50MHz Dual Channels
| 50MHz Dual Channels
|
