UNI-T MSO2102-S Digital Oscilloscope
100 MHz, 2+16 CH, Digital Logic Probe Included, 2 GSa/s, Memory Depth: 56 Mpts, 1,000,000wfms/s, 8in touch screen,built-in 2CH, 50 MHz signal generator
Couldn't load pickup availability
5-Year Warranty Coverage
Enjoy peace of mind with a 3-Year Standard Warranty, plus receive an additional 2 years when you register your product on our website.
👉 Register now at: Product Registration
Specifications
Specifications
-
Bandwidth100MHz
-
Channel2 +16
-
Real-Time Sample Rate2GSa/s
-
Waveform Capture Rate1.000,000wfms/s
-
Max. Memory Depth56Mpts
-
Waveform Generator50MHz Dual Channels
Description
- Analog Bandwidth: 100 MHz
- Analog Channels: 2
- Digital Channels: 16
- Real-Time Sampling Rate: 2 GSa/s (analog), 1 GSa/s (digital)
- Memory Depth: 56 Mpts per channel
- Waveform Capture Rate: Up to 1,000,000 wfms/s
- Waveform Generator: Built-in dual-channel 50 MHz arbitrary/function generator
- AWG Output: Supports real-time export of oscilloscope waveforms to the AWG
- Bode Plot: Built-in loop test analysis for system stability
- Waveform Recording: Uninterrupted hardware recording of up to 120,000 frames
- Math Functions: Addition, subtraction, multiplication, division, logic operations, filtering, and advanced calculations
- FFT Analysis: 4Mpts enhanced FFT with frequency markers, detection settings, and waterfall diagram
- Parameter Measurements: 36 automatic waveform parameters
- Scan Measurement: Real-time parameter measurement during signal scanning
- Multi-Scopes Mode: Independent channel triggering and phosphor-style signal display
- Frequency Counter: Multi-channel 7-digit hardware counter with adjustable refresh
- DVM Function: True RMS support for DC, AC, and DC+AC signals
- Trigger Types: Edge, Pulse, Video, Slope, Runt, Over Amplitude, Delay, Timeout, Duration, Setup/Hold, Nth Edge, Pattern
- Zone Triggering: Capture rare and complex signals with precision
- Protocol Decoding (Optional): RS232, I2C, SPI, CAN, CAN-FD, LIN, FlexRay
- Display: 8-inch capacitive touchscreen (800×480) with gesture controls: click, slide, zoom, edit, drag
- Display Technology: Ultra Phosphor with 256 grayscale levels
- Interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail), AWG, VGA
- SCPI Support: Supports SCPI standard commands for automated control
- Remote Access: Built-in web server for browser-based remote operation (PC and mobile)
Product comparison
| Facet | ||||
|---|---|---|---|---|
| By | ||||
| By | UNI-T | UNI-T | UNI-T | UNI-T |
| Price | ||||
| Price |
£790.00
excl. VAT
Unit price
/
Unavailable
£948.00
Incl. VAT
|
£707.00
excl. VAT
Unit price
/
Unavailable
£848.40
Incl. VAT
|
£749.00
excl. VAT
Unit price
/
Unavailable
£898.80
Incl. VAT
|
£832.00
excl. VAT
Unit price
/
Unavailable
£998.40
Incl. VAT
|
| Bandwidth | ||||
| Bandwidth | 100MHz
| 100MHz
| 200MHz
| 200MHz
|
| Channel | ||||
| Channel | 4+16
| 2 +16
| 2+16
| 4+16
|
| Max. Memory Depth | ||||
| Max. Memory Depth | 56Mpts
| 56Mpts
| 56Mpts
| 56Mpts
|
| Real-Time Sample Rate | ||||
| Real-Time Sample Rate | 2GSa/s
| 2GSa/s
| 2GSa/s
| 2GSa/s
|
| Waveform Capture Rate | ||||
| Waveform Capture Rate | 1.000,000wfms/s
| 1.000,000wfms/s
| 1.000,000wfms/s
| 1.000,000wfms/s
|
| Waveform Generator | ||||
| Waveform Generator | 50MHz Dual Channels
| 50MHz Dual Channels
| 50MHz Dual Channels
| 50MHz Dual Channels
|
