UNI-T UPO1104 Digital Oscilloscope

100MHz, 2 GSa/s, 4 CH, Memory Depth: 56 Mpts, 500,000 wfm/s, 7in display

£407.00 excl. VAT
£488.40 Incl. VAT

Variants

Buttons

Delivery Content
Warranty

Specifications
  • Bandwidth
    100 MHz
  • Channel
    4
  • Real-Time Sample Rate
    2 GSa/s
  • Waveform Capture Rate
    500,000 wfms/s
  • Max. Memory Depth
    56 Mpts
  • Waveform Generator
    -

Description

  • Analog channel bandwidth: 100 MHz
  • Analog channel number: 4
  • Maximum sampling rate: 2GSa/s
  • Vertical scale: 500μV/div to 20 V/div
  • Low-base noise: <100μVrms
  • Maximum memory depth: up to 56Mpts
  • Waveform capture rate: up to 500,000 wfms/s
  • Continuous waveform recording: up to 120,000 frames in real time
  • Automatic measurement of 36 waveform parameters, divided into screen and cursor areas
  • Supports 7-digit hardware frequency counter measurement
  • DVM supports AC/DC TRMS (true RMS) measurement
  • Waveform calculation functions: FFT, add, subtract, multiply, divide, digital filter, logical operation, and advanced operations
  • 1M sampling points to enhance FFT function, supports frequency setting, waterfall curve, demodulation mode, and marker measurement
  • Multiple trigger functions: edge, pulse width, video, slope, runt pulse, over-amplitude pulse, delay, timeout, duration, setup/hold, Nth edge, and code pattern
  • Supports RS232, I2C, SPI trigger
  • Innovative RS232, I2C, SPI full memory hardware for real-time decoding
  • Ultra phosphor display effect with 256 grayscale display
  • 7-inch WVGA (800x480) TFT LCD
  • Multiple interfaces: USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail, DVM)
  • Supports waveform navigation, markers, and segmentation
  • SCPI programmable standard command support
  • Web access and control supported

    • Download
