UNI-T UT213A 400A Digital Clamp Meter

UNI-T UT213A 400A Digital Clamp Meter

The UT213 Series 400A Digital Clamp Meters come with certifications including CE, UKCA, and cETLus. Key features include auto range, relative mode, NCV/continuity buzzer, data hold, LCD backlight, flashlight, low battery indication (≤3.6V), input protection, and auto power off for efficient and accurate measurements.
Regular price £39.99
Regular price Sale price £39.99
Sale Sold out

Price with tax: £47.99

Shipping calculated at checkout.

Next Day Delivery & Free Shipping in the United Kingdom

Order Before 3:00 PM and we'll ship your package the next business day.

View full details

Collapsible content

Details

Features of UT213 Series 400A Digital Clamp Meters

  • Auto range
  • Relative mode
  • NCV/continuity buzzer
  • Data hold/LCD backlight
  •  Flashlight
  • Low battery indication: ≤3.6V
  • Input protection
  • Auto power off
  • Certifications: CE, UKCA, cETLus

specification & comparison


Specifications Range UT213A UT213B UT213C
AC current (A) 400A ±(1.8%+9) ±(1.8%+9) ±(2.5%+5)
DC current (A) 400A ±(2%+3)
AC voltage (V) 600V ±(1.2%+5) ±(1.2%+5) ±(1.2%+5)
DC voltage (V) 600V ±(0.8%+1) ±(0.8%+1) ±(0.8%+3)
Resistance (Ω) 40MΩ ±(1%+2) ±(1%+2) ±(1%+2)
Capacitance (F) 100μF ±(4%+5)
40mF ±(4%+5) ±(4%+5)
Frequency 10Hz~1MHz ±(0.1%+4) ±(0.1%+4) ±(0.1%+4)
Temperature -40℃~1000℃ ±(1%+3) ±(1%+3)
-40℉~1832℉ ±(1%+6) ±(1%+6)
Features
Display count 4000 4000 4000
Auto range
Jaw opening 30mm 30mm 30mm
True RMS
Diode Around 1.5V Around 3.0V Around 3.0V
NCV
Data hold
Relative mode
MAX/MIN
LCD backlight
Flashlight
Auto power off
Continuity buzzer
Low battery indication
Input protection
Input impedance for DCV
General Characteristics
Power 1.5V battery (R03) x 3
Display 38mm x 24mm
Product net weight Red and grey
Product color UT213A/B: 280g; UT213C: 231.7g
Product size 220mm x 75mm x 40mm
Standard accessories Batteries, test leads (UT213B/UT213C), point contact temperature probe (UT213B/UT213C)
Standard individual packing Gift box, carrying bag, English manual
Standard quantity per carton 40pcs
Standard carton measurement 485mm x 345mm x 385mm
Standard carton gross weight UT213A: 18.2kg; UT213B: 19.6kg; UT213C: 19.4kg
