UNI-T UT595 Multifunction Installation Testers

UNI-T UT595 Multifunction Installation Testers

 The primary functions of the Multifunctional Installation Tester series multifunction testers are to test AC/DC voltage, RCD, loop/line impedance, earth resistance continuity, and insulation resistance. They can be used in the construction industry or for home electrical installation, inspection, and repair.

UT593, UT595 are the models in the Multifunctional Installation Tester Series.



Regular price £378.99
Regular price Sale price £378.99
Sale Sold out

Price with tax: £454.79

Shipping calculated at checkout.

Next Day Delivery & Free Shipping in the United Kingdom

Order Before 3:00 PM and we'll ship your package the next business day.

View full details

Collapsible content

Details

● 9999-count LCD display with analogue bar

● 250V~1000V DC insulation resistance test

● 200mA earth-resistance continuity test

● Loop impedance/Prospective Fault Current (PFC)/Prospective Short Current (PSC) test

● Lock test

● RCD trip time test and the data storage with one key

● Full/Half wave and count downing (30s) test mode selectable

● 0°/180° phase angle option to detect the fastest trigger time

● Trip current test of RCD trip time X2

● RCD trip trigger current test

● Phase sequence and missing test

● AC/DC voltage auto check and test

● Connection check with status real-time display

● White backlight; auto power off

● Certifications: CE

specification & comparison

Specifications Range UT593 UT595
Insulation resistance (Ω) Output voltage 250V/500V/1000V ±10%
250V 0.05MΩ~250MΩ ±(5%+5)
500V 0.05MΩ~500MΩ
1000V 0.05MΩ~1000MΩ
Short-circuit current   <2mA
Low-resistance continuity test Range 0.00Ω~199Ω ±(2%+5)
Test current 0.00~2Ω: >200mA
Line impedance (Ω) Range 0.01Ω~2000Ω ±(5%+5)
Operating voltage (Frequency) 230V (45Hz~65Hz)
Test current 20A
PFC test 0kA~26kA
Loop impedance (Ω) Range 0.01Ω~2000Ω ±(5%+5)
Operating voltage (Frequency) 195V~253V (45Hz~65Hz)
Test current 20A
PFC test 0kA~26kA
Non-trip loop impedance (Ω) Range 1.00Ω~2000Ω ±(5%+5)
Operating voltage (Frequency) 195V~253V (45Hz~65Hz)
Test current 15mA
PFC test 0kA~26kA
RCD test Operating voltage (Frequency) 195V~253V (45Hz~65Hz)
Test current 10mA/30mA/100mA/300mA/500mA ±10%
Trip time ×1/2 *I△n Range: 0ms~2000ms ±(5%+5)
×1 *I△n Range: 0ms~300ms
×1 *I△n Range: 0ms~500ms (Select count down)
×2 *I△n Range: 0ms~150ms   ±(5%+5)
×2 *I△n Range: 0ms~200ms (Select count down)   ±(5%+5)
×5 *I△n Range: 0ms~40ms ±(5%+5)
Phase sequence test Operating voltage (Frequency) 100V~440V (45Hz~65Hz)
Display Phase sequence: L1→ L2→ L3, forward rotation; L1→ L3→ L2 reverse rotation
Ramp RCD test Test current 10mA/30mA/100mA/300mA/500mA ±10%
AC voltage (V) Range 0V~440V ±(5%+2)
Frequency response 45Hz~60Hz
Resolution 1V
Features
Display count   9999
Auto power off
Low battery indication
Data storage
LCD backlight
Auto half-wave test
RCD count down test 30s
RCD half-wave test
Phase conversion (RCD) 0° and 180°
General Characteristics
Power 1.5V battery (5#) × 6
LCD size 125mm × 37mm
Product color Red and grey
Product net weight 1000g
Product size 210mm × 175mm × 90 mm
Standard accessories Battery, test leads (red×1, green×1, black×1), special power test lead, remote-control test lead
Standard individual packing Gift box, manual, tool box
Standard quantity per carton 4pcs
Standard carton measurement 510mm×330mm×300mm
Standard carton gross weight 15kg
