UNI-T MSO/UPO3000CS/E-I2C
- UNI‑T MSO/UPO3000CS/E‑I²C Embedded Serial Bus Trigger & Analysis Option
- Designed for MSO3000E and UPO3000E series oscilloscopes
- Enables I²C (Inter‑Integrated Circuit) bus triggering and real-time decoding
- Supports START/STOP detection, 7‑bit and 10‑bit address recognition, data byte capture, and ACK/NACK error identification
- Offers advanced trigger options on address matching, specific data patterns, arbitration loss, and bus collision events
- Displays time-aligned analog waveforms alongside decoded I²C traffic for precise timing and signal correlation
- Ideal for embedded system development, sensor interface testing, and microcontroller communication debugging
- Seamlessly integrates with MSO/UPO3000E firmware and UI for streamlined mixed-signal analysis
£236.99
excl. VAT
Unit price
/
Unavailable
£284.39
Incl. VAT
